VisiJet M2E-BK70 Resin Cartridge - 3D Systems

SKU 24243-915

Name and surname *

Phone number

Email address *

Message *

I have read and agree to the privacy policy

The item has been added to your cart

Go to cart

You have reached the maximum quantity that can be added to the cart

Go to cart

Description
Technical Specifications

A tough, black elastomer with a high Shore A hardness of 70 and excellent rebound after compression

VisiJet M2E-BK70 is an elastomeric material with a Shore A hardness of 70, that shows very good shape memory. Exhibiting best-in-class compression and rebound properties, this material can be used for a variety of design and prototyping applications such as seals, gaskets, sensor pads and cable guides.

Download Brochure here

Material Type: Visijet M2 Series

Application: Prototyping

Applications

Design and prototyping applications of medium hard rubber-like products, such as:
- Seals
- Gaskets
- Sensor pads
- Cable guide
- Bumpers
- Treads
- Grips and handle

Benefits

Best compression in its class
Excellent compression rebound without crumbling
Feature fidelity, sharp edges
Smooth surface quality
UL94 HB flammability test standards
USP Class VI certified for biocompatibility

Features

Shore A hardness of 70
Good rebound properties
Outstanding compressive properties
Very good shape memory/spring back
Biocompatible*
For use with the ProJet® MJP 2500 Plus

* Biocompatibility is based on testing by an independent testing lab on a single geometry and sample set per USP Class VI. Users should confirm fitness for use and biocompatibility for their applications.

Key Mechanical Properties

Elongation at break: 44%
Tensile modulus: 6.4 MPa
Tensile strength: 2.9 MPa
Shore A hardness: 73
Tear Strength: 6.8 kN/m
Compression set: 0.5%
Water absorption (24 hr): 1.2%
